Elo 1291L 12-Inch Open Frame Touchscreen Display
Price range: €711.48 through €774.44
The Elo 1291L 12-inch open-frame LCD touchscreen features a slim design and narrow outside dimensions thanks to the state-of-the-art, energy-saving LED backlight, using less electricity to operate and generating less heat.
This compact display is designed for touch with proven Elo expertise and reliability built in. The 1291L provides stable, drift-free operation with outstanding image clarity and light transmission—for accurate touch responses and vivid images.
Featuring a brilliant wide viewing angle panel, the open-frame touchscreen instantly grabs and holds the users’ attention for kiosks, casino and amusement, retail self-service, and industrial automation environments.
- Description
- Size Guide
- Additional information
- Reviews (0)
- Specifications
Description
Elo 1291L 12-Inch Open Frame Touchscreen Display
The Elo 1291L is a highly durable 12-inch open frame touchscreen display, purpose-built for OEMs, kiosk integrators, and commercial environments that demand long-lasting reliability. Designed with Elo’s industry-leading expertise, the 1291L delivers crystal-clear imagery, accurate touch performance, and stable drift-free operation, making it ideal for self-service applications, retail kiosks, gaming terminals, healthcare systems, and industrial automation.
Industrial-Grade Quality & Versatility
The Elo 1291L features a commercial-grade LCD WVA panel with LED backlight, offering exceptional clarity, wide viewing angles, and reduced power consumption. Its slim, zero-bezel design and narrow outer dimensions make it easy to integrate into a wide range of kiosk housings, cabinets, and enclosures.
Choose between Projected Capacitive (PCAP) 10-touch or IntelliTouch surface acoustic wave technology—both engineered to deliver reliable, high-precision touch performance in demanding environments.
Touch Thru Glass Support
Equipped with Elo’s advanced TouchPro® PCAP technology, the 1291L supports touch thru glass for installations requiring an extra protective cover layer up to 6mm thick. This makes it ideal for:
-
Fully enclosed kiosks
-
Harsh industrial settings
-
Public self-service terminals
-
High-usage gaming cabinets
Regardless of the setup, the touchscreen maintains excellent responsiveness and durability.
Flexible Mounting for Any Installation
Built for maximum adaptability, the Elo 1291L can be mounted in landscape, portrait, or face-up orientation. This flexibility allows seamless integration into:
-
Interactive kiosks
-
POS systems
-
Information terminals
-
Control panels
-
Medical carts
-
Custom industrial machines
No matter the viewing angle or distance, the display maintains optimal clarity and performance.
Smart Kiosk Management with EloView® + Elo Backpack™
When paired with the Elo Backpack™ Android compute engine, the 1291L becomes a powerful, scalable media platform. Through EloView®, users can remotely deploy content, monitor device health, and manage applications—making fleet operations simple and efficient.
This combination provides:
-
Low-power, fan-less operation
-
Simplified deployment
-
Centralized kiosk management
-
Solid-state reliability
Built to Last in Commercial Environments
Elo’s open frame touchscreens undergo rigorous testing to ensure long-term durability and low total cost of ownership. The 1291L is engineered for continuous 24/7 operation, offering:
-
Reliable, drift-free touch performance
-
Robust construction for high-traffic environments
-
Long product availability for seamless integration cycles
Key Specifications
-
Screen Size: 12-inch LCD (WVA, LED backlight)
-
Touch Technology: PCAP 10-touch Zero-Bezel / IntelliTouch
-
Interfaces: HDMI, VGA, DisplayPort
-
Touch Interface: USB
-
Mounting: Open frame, flexible orientation options
-
Version: Worldwide
| size | chest(in.) | waist(in.) | hips(in.) |
|---|---|---|---|
| XS | 34-36 | 27-29 | 34.5-36.5 |
| S | 36-38 | 29-31 | 36.5-38.5 |
| M | 38-40 | 31-33 | 38.5-40.5 |
| L | 40-42 | 33-36 | 40.5-43.5 |
| XL | 42-45 | 36-40 | 43.5-47.5 |
| XXL | 45-48 | 40-44 | 47.5-51.5 |
Additional information
| Options: | 1291L TouchPro PCAP [Mfr Part # E331595], 1291L IntelliTouch [Mfr Part # E329452] |
|---|
Be the first to review “Elo 1291L 12-Inch Open Frame Touchscreen Display”
IntelliTouch (Worldwide) – E329452
TouchPro PCAP (Worldwide) – E331595
Enclosure Color: Black
Touch Technology & Capacity:
SAW (IntelliTouch? Surface Acoustic Wave) – Single Touch
PCAP (TouchPro? Projected Capacitive) – 10 Touch
Touch Interface:
TouchPro PCAP – USB 2.0
IntelliTouch – Dual serial/USB 2.0
Diagonal Size: 12.1” diagonal, Active matrix TFT LCD (LED)
On Screen Display:
Accessible through switches on the unit?s tethered OSD Control box.
Controls: Menu, Up, Down, Select, Power
Settings: Brightness, Contrast, Clock, Phase, H-position, V-position, Auto-Adjust, Sharpness, Color Temperature, OSD Timeout, OSD Language, OSD H-Position, OSD V-Position, Recall Defaults, Video Priority, Information, Touch On Sleep Mode, Touch Thru
Languages: English, French, Italian, German, Spanish, Simplified Chinese, Traditional Chinese, Japanese
Lockouts: OSD, Power
Aspect Ratio: 4:3
Active Area (mm): 9.69″ x 7.26″/ 246mm x 184.50mm
Resolution: 800 x 600 at 60 Hz
Other Supported Resolutions:
640 x 480 60Hz
800 x 500 60Hz
800 x 600 60Hz
1024×768 60Hz
1280 x 720 60Hz
Viewing Angle: Horizontal: ?89? or 178? total / Vertical: ?89? or 178? total
Number of Colors: 16.2 million
Brightness (typical):
LCD panel: 450 nits
IntelliTouch: 405 nits
TouchPro PCAP: 405 nits
Response Time-total (typical): 25 msec
Contrast Ratio: 1500:1
Input Video Format:
HDMI V1.3 Type A receptacle for HDMI input
Analog VGA on Female DB-15 connector
DisplayPort V1.1a – Supports later versions of Display Port video input
Input Video Frequency:
Horizontal: 30 – 38 KHz
Vertical: 50 – 75 Hz
Video Interface: HDMI, VGA & Display Port
Power Supply: External DC – Optional power brick (sold separately)
Input power connector (Monitor): Coaxial power jack (2.0mm (+0.0 -0.1mm) pin outer diameter, 6.4mm (+/- 0.3mm) barrel inner diameter, 8.8mm (+/- 0.3mm) barrel depth)
Input Voltage: 12VDC +/- 5%
Adapter Output Power Connector: DC barrel plug (2.1mm (+/- 0.1mm) pin inner diameter, 5.5mm (+/- 0.05mm) barrel outer diameter, 9.5mm (+/- 0.3mm) barrel length)
Power Consumption (Typical):
Monitor + Adapter at 230V/50Hz
ON: 12.2 W
SLEEP: 1.5 W
OFF: 0.5W
Dimensions:
Bezel: 11.91″ x 9.54″ x 1.96″ / 302.5mm x 242.2mm x 49.8mm
Zero-Bezel: 11.90″ x 9.53″ x 1.77″ / 302.5mm x 242mm x 44.9mm
Shipping Box Dimensions: 15.12″ x 12.68″ x 14.38″ / 384mm x 322mm x 185mm
Weight (Unpackaged): 5.8 lbs / 2.65 Kg
Weight (Packaged): 10.5 lbs / 4.75 Kg
Operating Temperature: 0?C to 40?C / 32?F to 104?F
Storage Temperature: -20?C to 60?C / -4?F to 140?F
Humidity:?
Operating: 20% to 80%
Storage: 10% to 95%
Sealability:?
Touchscreen sealed to bezel
Touchscreen sealed to LCD
MTBF: 50,000 hours demonstrated
Warranty: 3-year
Extended Warranty Options:
4 year warranty coverage?- Elo P/N:?E898247
5 year warranty coverage?- Elo P/N:?E898449
3 year warranty coverage + AUR?- Elo P/N:?E898648
4 year warranty coverage + AUR?- Elo P/N:?E894921
5 year warranty coverage + AUR?- Elo P/N:?E895125
Regulatory approvals and declarations: Australia RCM; Canada cUL, IC; China CCC; Europe CE TUV; United Kingdom UKCA; Japan VCCI; Korea KCC; Mexico CoC; Taiwan BSMI; United States UL, FCC; International CB; RoHS, China RoHS, WEEE
Mounting Options:?
4-hole 75mm VESA mount
Rear mount through bezel or with included mounting brackets (IntelliTouch models).
Flush mount with included mounting brackets (TouchPro PCAP models)
See dimensional drawings for details
What’s in the Box:
HDMI cable
VGA Cable
RJ45 OSD Remote
Touch USB Cable
Quick Install Guide
For Zero-Bezel Models: Flush Mount Brackets w/Screws
For Bezeled Models: ?L? (Side Mount) Brackets and w/Screws
EEI Label
Japan Class-B TM info sheet
Options / Peripherals / Upgrades:
Elo Remote OSD (RJ45) – Elo P/N: E483757
Elo Backpack? – Elo P/N: E611864
Elo Backpack? 3.0 – Elo P/N: E901355
Replacement Cable Kit – Elo P/N: E546861
Cable Kit DVI-D to HDMI ? Elo P/N: E538507
Cable Kit DP to DP ? Elo P/N: E582895
North America power brick – Elo P/N: E005277
European & Korea power brick – Elo P/N: E571601
UK power brick – Elo P/N: E180092
China power brick – Elo P/N: E558862
Taiwan power brick – Elo P/N: E818655
Japan power brick – Elo P/N: E182546
Argentina power brick – Elo P/N: E887099
Australia power brick – Elo P/N: E637593
IntelliTouch Stylus Pen – Elo P/N: D82064-000
Elo 12-inch – L-Bracket – Elo P/N: E549171
Elo 12-inch Flush mount Bracket – Elo P/N: E548984
Power DC 24V/DC 12V Converter – Elo P/N: E239980
Optional PCAP Stylus Pen: E066148
